Rotation Interactive Flat Panel
- Size27" / 32"
- Touch10-point PCAP multi-touch with low latency and palm rejection
- Operating SystemAndroid 13 EDLA-certified with Google Play
- RotationFree 360° rotation between landscape and portrait
- BatteryBuilt-in rechargeable battery for mobile deployments
- MobilityHeavy-duty wheels + battery, no power cord required
- Brightness300–500 cd/m² (indoor)
- Use CaseCreative retail, mobile collaboration, classrooms, events
- Cloud CMSBuilt-in CMS for content push and remote control
12 hrs Quotation SLA
3-year Warranty
50 units MOQ · OEM
Full specifications
Detailed parameters for channel deployment. Verified spec sheets available on request.
Display
Size27" / 32"
ResolutionFHD (1920×1080) · 4K UHD option
Touch technology10-point PCAP · low latency · palm rejection
Operating systemAndroid 13 EDLA · Google Play pre-installed
Brightness300–500 cd/m²
Color depth16.7M (8-bit)
Viewing angle178° H / 178° V
RotationFree 90° rotation · portrait/landscape
System & Connectivity
BatteryBuilt-in lithium battery · 6–8 hours continuous use
WheelsLockable heavy-duty casters
NetworkWi-Fi 6 · Bluetooth 5.0 · Ethernet (RJ45)
Camera4K optional · array microphone optional
InputUSB-C × 1 · HDMI × 1 · USB × 2 · LAN
PowerAC 100–240V · 50/60 Hz · battery charging
Operating temp0°C to 35°C
Weight27": 28kg · 32": 35kg (with battery)
Frequently asked questions
Quick reference on size, MOQ, lead time, customization and warranty. For project-specific questions, contact our sales team.
How long does the battery last?
6–8 hours of continuous use at typical brightness. Heavy use (max brightness, video playback) reduces to 4–5 hours. Standby time is 24+ hours. Full charge takes 3–4 hours from empty.
Can I install my own apps?
Yes. EDLA-certified Android 13 includes Google Play. Install any Android app — productivity, collaboration, education, retail. TZ Display does not restrict app installation.
Is the rotation motorized or manual?
Standard models use manual rotation — push the screen, it rotates smoothly to the next detent. Motorized rotation is available as an option for digital poster use cases where the screen auto-rotates based on content orientation.
What is the typical lead time?
Standard SKUs ship within 15–25 business days after PO confirmation. Custom OEM projects typically run 30–45 business days from artwork approval to first article. Detailed lead time provided in the quotation.
What warranty and support is included?
3-year standard warranty on all commercial display products. Spare parts, RMA workflow, remote diagnostic support and on-site engineering for qualified project orders. Multi-language support in English, Chinese, Spanish, Portuguese, Arabic and Russian.
Tell us your project. We'll recommend the right display configuration.
Send product type, quantity, target country and branding needs. Our sales team replies within 12 business hours with model suggestions, OEM options, lead time and a factory quotation.
