Ultra-Slim QLED Display
43"/55" QLED 4K UHD with built-in CMS. Pair for room-to-room consistency in flagship retail.
View specs →Mini LED Display
Premium displays with up to 2000 nits peak brightness and 1,000,000:1 contrast ratio via local dimming. Anti-glare 3H coating, ultra-narrow 6.9mm equilateral bezel, 35–50% energy saving. Engineered for high-end retail, boardrooms and command centers.
12 hrsQuotation SLA
3-yearWarranty
50 unitsMOQ · OEM
3-yearWarranty
50 unitsMOQ · OEM
Display
43"–86"
Resolution
4K UHD (3840×2160)
Brightness
1,000,000:1 (local dimming)
Lead time
15–25 business days (PO)
Full specifications
Detailed parameters for channel deployment. Verified spec sheets available on request.
Display
Size range43"–86"
BacklightMini LED with local dimming zones
Resolution4K UHD (3840×2160)
Brightness700 / 1500 / 2000 nits peak
Contrast1,000,000:1 (local dimming)
Color depth1.07G (10-bit) · 95% DCI-P3
Viewing angle178° H / 178° V
Anti-glare3H coating · 25% haze
System & Connectivity
Energy saving35%–50% vs conventional edge-lit LCD
Bezel6.9mm equilateral · ultra-narrow
Multi-screenSuitable for multi-screen seamless splicing
Operating systemAndroid · Windows (optional)
InputHDMI × 2 · USB × 2 · DisplayPort · LAN
NetworkWi-Fi · Bluetooth · Ethernet (RJ45)
CMSWeb-based · Cloud · Private-label ready
Operating temp0°C to 40°C · 10–80% RH
Engineered for commercial duty
Capabilities that separate consumer TVs from commercial signage. Each addresses a real channel deployment need.
1,000,000:1 contrast via local dimming
Mini LED backlight with thousands of independently-controlled dimming zones. Blacks are truly black, highlights are true-to-source. Critical for premium content and high-ambient-light environments.
35–50% energy saving
Local dimming enables dynamic power reduction. Dark scenes draw less power than bright scenes. Real-world energy savings of 35–50% vs conventional edge-lit LCD at equivalent brightness.
6.9mm ultra-narrow bezel
Equilateral 6.9mm bezel on all four sides. Multi-screen video walls show minimal seams. Premium aesthetic for boardrooms and high-end retail.
95% DCI-P3 color gamut
Wide color gamut coverage suitable for color-critical content — photography studios, design firms, medical imaging, broadcast post-production.
Anti-glare 3H coating
Chemically hardened anti-glare coating reduces reflections in high-ambient-light environments. 3H hardness rating for scratch resistance in commercial use.
2000 nits peak brightness
Suitable for high-ambient-light retail windows, atrium placements, and sun-facing installations. Optional anti-glare upgrade available for direct sunlight.
Application scenarios
High-volume channel deployments. Standard SKUs with optional branding, packaging and firmware customization.
Premium retail flagship stores
High-end flagship retail where product photography and brand visuals demand color accuracy and contrast. Apple-style stores, luxury fashion, jewelry.
Executive boardrooms
Boardroom displays where C-suite presentations need true-to-source color reproduction. 4K UHD, 95% DCI-P3, ultra-narrow bezel for video conferencing backdrops.
Command & control centers
24/7 control room displays with multi-screen splicing. High contrast for video monitoring, low power consumption for always-on operation.
Broadcast & post-production
Reference monitoring for video post-production. 4K UHD, 1.07G color, 95% DCI-P3. Suitable for client review and color grading bays.
OEM customization built in
ZSH Mini LED Display is engineered as a private-label platform. From project kickoff to first article in 30–45 business days. Configure any combination below — your SKU, your brand, your market.
Logo & boot screenReplace splash, system UI, packaging
Housing colorBlack, white, custom RAL
Hardware configRAM, storage, I/O port layout
Private-label CMSApp name, login, branding
PackagingMulti-language manuals, gift box
CertificationsCE · FCC · RoHS · ISO 9001
Related products
ZSH product families that pair for end-to-end channel programs.
Frequently asked questions
Quick reference on size, MOQ, lead time, customization and warranty. For project-specific questions, contact our sales team.
What is local dimming and why does it matter?
Local dimming is a backlight technology where the LED backlight is divided into thousands of independent zones. Each zone dims or brightens based on the content in that area. Black areas of the image are truly black (no backlight), bright areas are bright. This produces much higher contrast (1,000,000:1) than conventional edge-lit LCD (1400:1). It's critical for HDR content and any high-ambient-light environment.
Is the 6.9mm bezel suitable for video walls?
Yes. The 6.9mm equilateral bezel is suitable for video wall installations. For ultra-narrow video walls (under 2mm seam), consider our dedicated LCD video wall product with 3.5mm bezel — though that uses conventional LCD technology without Mini LED backlight.
What content benefits most from Mini LED?
HDR content (High Dynamic Range), high-contrast video (cinema, nature documentaries), color-critical content (product photography, fashion, jewelry), and any content shown in high-ambient-light environments. For standard office content (spreadsheets, presentations), the benefit is less pronounced.
What is the typical lead time?
Standard SKUs ship within 15–25 business days after PO confirmation. Custom OEM projects typically run 30–45 business days from artwork approval to first article. Detailed lead time provided in the quotation.
What warranty and support is included?
3-year standard warranty on all commercial display products. Spare parts, RMA workflow, remote diagnostic support and on-site engineering for qualified project orders. Multi-language support in English, Chinese, Spanish, Portuguese, Arabic and Russian.
Get a quote for mini led display
Send quantity, target market and customization needs. Our sales team replies within 12 business hours with model suggestions, OEM options and FOB Shenzhen pricing.
